Technical specification
Compatible products
Rotation Unlimited
Max. axial load static 30 kN (6745 lbf)
Max. axial load dynamic 15 kN (3372 lbf)
Torque 1000 Nm (738 lb ft)
Rec. oilflow 20 l/min (5.3 US gallon)
Weight 18 kg (39 lb)
Upper connection L 73 mm (2.87 in)
Upper connection D 25 mm (0.98 in)
Lower Axle d & hole D
Lower Flange d x pos & bolt hole D
Warranty 2 years
